Contec TLC 9803 Holter ECG System (3-Channel)

PRODUCT DESCRIPTION

• Digital Display : Yes
• Brand : Contec (Niscomed)
• Model : TLC 9803
• Machine Type : Portable
• Operating Mode : Automatic

FEATURES

• With Advance Design And Technology. The Recorder Can Work Stably, Dependable And Durably.
• Be Provided With The Capability Of Anti-jamming And Aseismatic.
• Small Volume With Oled Screen. The Resolution Is 160#128.
• Be provided with functions of waveform preview, record review and event marketing.
• Accurate record of the start time of the data sampled owing to the real time clock of itself.
• Avoid damage owing to the repeating inserting and pulling out by using the inbuilt TFcard to storage the data.
• The maximum capability can be 2gb , so the original data can be saved perfectly by no compression.
• the average review time of single case can be less than 40 seconds by using interface of USB 2.0.
• Record waveform details inextenso by the design of high precision sampling frequency.
• Record the state of pacemaker exactly by higher sampling frequency.
• International standard of 12 leads , record 24-hour Drcg with the same standard of the ECG.

STANDARD:

• Number of channel : 3 channel
• Record Time : 24h
• Interface : Usb 2.0
• Standard Sensitivity : 10mm\mv+5%
• Cmrr : >60db
• Low frequency characteristics Time constans t >3.2s:
• Scan speed : 25mm\s+5%
• Enduring polarization voltage : +300mv Dc polarization sensitivity shift < + 10%
• Least measuring signal : 50 u V p-p
• Product safety type : Type B (internally powered)
• Sampling accuracy  : 12Bit
• Power                    :  2AA size Batteries
• Scale voltage          :  1m V+5%
• Noise Level             :  < 30uV

CONTENT OF BOX

Main device
Pouch
Power cord
Probes
User Manual

Warranty : 1 Year
