RMS Neurological Advance Bio-Feedback System Relax 701
PRODUCT DESCRIPTION
FEATURES
- Compact and lightweight.100
- Data communication through a single USB
- Battery operated machine
- On-Screen Impedance check
- In-built speaker for EMG test
- Suitable for use in bedside recording
- Reports can be e-mailed or transferred across a network
PRODUCT SPECIFICATIONS
| CHANNELS | 2 |
| SENSITIVITY | 0.1,0.2,0.5,1,2,5,10,20,50,100,200,500uV/div;1,2,5,10mV/div |
| HIGHCUT | 2 pole (12dB/octave) filter,100,200,500,Hz;1,2,3,5,10 kHz |
| LOWCUT | 0.2,2,20,30,100,500Hz |
| SWEEP SPEED | 1 to 1000ms/div in 3 steps (1,1.5,2,3,5,7.5,10,15,20,30,50,75,100,200,300,500) |
| EMG | 2 to 500ms/div in 3 steps (2,4,6,10,20,30,50,75,100,200,300,500) |
| CMRR | >100dB |
| INPUT IMPEDANCE | >100 Mohms |
| NOISE | <0.5uV rms (1Hz to 10 kHz) |
| A/D CONVERTOR | 16 bit analog digital conversion |
| ELECTRICAL STIMULATOR |
TYPE: Hand held,constant current electrical stimulator with stimulus intensity dial and stimulus trigger on handle. save and start/stop switches are provide on stimhandle DURATION: 0.02,0.05,0.10,0.20,0.50,1.0 ms REPETITION RATES: 0.5,1,3,5,7,10,15,20,25,30 PPS standard or any user defined value ISOLATION: Electrical isolated stimulator with independent controls ELECTRICAL RANGE:0-100 mA with adjustable duration, intensity and repetitive rate |
| AUDITORY STIMULATOR |
TYPE: Headphone STIMULUS: Click ,pips FREQUENCY: 0.5Hz to 8000Hz INTENSITY: 0-110 dBnHL or 30-140 dB SPL CLICK DURATION: 100 uS,Square wave click,rarefraction,condensation or alternating polarity ENVELOPES: Linear ,gausian,black man,hanning WHITE NOISE: Contral lateral masking from 0 dB to 80 dB nHL RATE : User definable |
| VISUAL STIMULATOR |
VIDEO MOINTOR: monochrome VEP monitor for black and white or color with user programmable colors, pattren reversal check board stimulation , veritical bus, horizontal bars, SQUAE SIZE: 2,3,4,5,6,7,8,9,11,13,16,21,32,64 FLASH MODE: Available RATE: User defined |
| POWER SUPPLY |
19V DC, 3.4 A through adaptor |
| DIMENSIONS |
745x765x465 in mm |
CONTENT OF BOX
- EMG electrodes
- Sensory ring electrodes
- EMG needle electrodes
- Stimulating electrodes
- Ground electrode
- Bar electrode
- EP electrode
- Jumper cable
- Conductive gel
- EP paste
- Measuring tape
- Marker
Warranty : 1 Year
